1X 60kg baja servo DS5160 SSG HV Digital Servo for 1/5 Redcat HPI Baja 5B SS RC Car compatible SAVOX-0236 LOSI XL 5T
Note: 1. The best use voltage is 7.4v.
It is recommended to use 2s battery for power supply (6v-8.4v)
2. The working angle of the servo is 180 degree or 270 degree (PWM: 500us-2500us)
Some remote controls can only output 1000-2000, it is recommended to buy 270 degree.
Package contains:
1 pieces of DS5160 Digital Metal Robotic Servo
1 pieces of 18T servo arm
one set of screw(see the picture)
Or
1 pieces of DS5160 Digital Metal Robotic Servo
1 pieces of 18T metal servo horn disk
one set of screw(see the picture)
Size:65*30*48(servo)
Weight:162g
Wire length:320mm
Speed: 0.17sec/60 degree at(6v)
0.15sec/60 degree at(7.4v)
0.13sec/60 degree at(8.4v)
Torque: 58kg.cm.at(6v)
65kg.cm.at(7.4v)
65kg.cm.at(7.4v)
70kg.cm.at(8.4v)
Voltage: 6v-8.4v
Dead Zoon setting:3 Microseconds
Features:
– Durable Metal Gear
– Dual Ball Bearing
– Programmable Digital Amplifier with Mosft Drive
– Bottom Side Axial Mount Hole
– Original factory product
– Less Noise
–Contains: Long Holder Aluminum & Short Holder Aluminum & Circle Holder-18T & Circle Holder –Orientation Angle:maximum 180 or 270 deg
-Mechanical Angle :360 deg
(Plug/Output wheel/Radio control system compatible with Futaba JR Hitec)
