RCPro 10A 12A 15A 20A 30A 40A 50A 70A 80A Firmware Electronic Speed Controller ESC for RC Multicopter Helicopter

$18.79$36.79
FREE SHIPPING! ⭐⭐⭐⭐⭐

-25%
76 (reviews)
SimonK 10ASimonk 12ASimonk 15ASimonK 20ASimonK 30A 4SSimonK 30A 6SSimonK 40ASimonk 50A-OPTOSimonK 70A-OPTOSimonK 80A-OPTO
Clear
  • Unique Products Only Found Here!
  • Free Shipping!
  • Lowest Prices!
  • 100% Money Back Guarantee!

This hardware, with the SimonK firmware, gives you the perfect solution for multirotor use:

simonk10A (2-3S):

Weight: 10 g
Size: 23.5x15x 6.1
Input voltage: (2-3 s Lixx).
Drive current: 10A (Max: 13 A/10S)
BEC Input :3V1A
Compatible signal frequency:30Hz – 499Hz

Simonk12A ( 2-3S ):

Weight:12g
Size:28*20*6.1
Input voltage:2-3S Lixx
Drive current:12A (Max:14A/10S)
BEC Input:5V2A
Compatible signal frequency: 30Hz – 499Hz

simonk15A (2-3S):

Weight:15g
Size:50*22*8
Input voltage:2-3S Lixx
Drive current:15A (Max:25A/10S)
BEC Input:5V2A
Compatible signal frequency: 30Hz – 499Hz

simonk20A (2-3S):

Cont Current: 20A
Burst Current: 28A
BEC Model: Linear mode
BEC Output: 5V3A
Li-ion/Li0poly:2-3S,or Ni-MH/Ni-Cd:4-12NIMH
Weight: 21g
Size: 32*24*7mm

simonk30A(2-4S):

Max cont. current: 30A
Peak current: 40A (10s)
Voltage: 2-3S lixx,
BEC: 5V/3A
Size: 50x23x8mm
Weight: ~28g

simonk30A-OPTO (2-6S)
(the ESC need the power from receiver or the flight control)

Weight:25g
Size:50*23*8
Input voltage: (3-6S Lixx)
Drive current:30A (Max:40A/10S)
BEC Input : NO
Compatible signal frequency: 30Hz – 500Hz

simonk40A(2-4S):

Weight:35g
Size:68*25*8MM
Input voltage:2-4S
Drive current:40A (Max:50A/10S)
BEC Input: 5V 3A
Compatible signal frequency: 30Hz – 500Hz

simonk50A-OPTO (2-6S)
(the ESC need the power from receiver or the flight control)

Weight:48g
Size:53*32*10
Input voltage: (2-6S Lixx)
Drive current:50A (Max:60A/10S)
BEC Input : NO
Compatible signal frequency: 30Hz – 500Hz

simonk70A-OPTO (2-6S)
(the ESC need the power from receiver or the flight control)

Weight:70G
Size:78*38*15MM
Input voltage: (2-6S Lixx)
Drive current:50A  (Max:85A/10S)
BEC Input : NO
Compatible signal frequency: 30Hz – 500Hz

simonk80A-OPTO (2-6S)
(the ESC need the power from receiver or the flight control)

Weight:75g
Size:78*38*15MM
Input voltage: (2-6S Lixx)
Drive current:50A (Max:90A/10S)
BEC Input : NO
Compatible signal frequency: 30Hz – 500Hz

Flashed with the famous SimonK OpenSource Firmware for super-fast throttle response, which makes your quad more responsive and “locked in”. Suited for quads up to 2.5kg, octos up to 5kg. The ESCs do not overheat, burn or lock out – unline many other ESCs flashed with the SimonK firmware.

The ESC motor leads are reduced to simple bullet connectors, this allows for quick and clean installation inside your multi rotor. Compatible with 2S to 3S battery

Additional information

Brand Name

U-Angel-1988

Origin

CN(Origin)

Material

Rubber

Recommend Age

12+y

Tool Supplies

Assembled class

Upgrade Parts/Accessories

Adapter

RC Parts & Accs

Speed Controllers

Use

Vehicles & Remote Control Toys

Quantity

1

Technical parameters

Value 2

Model Number

THC002103

Remote Control Peripherals/Devices

ESC

For Vehicle Type

Airplanes

Four-wheel Drive Attributes

Motors

Wheelbase

Screws

is_customized

Yes
